AT-FL Series |
|
|
|
 |
| |
|
| Spiral bevel gearbox with two output shaft. Input with motor adapter. |
|
- Output torque
T2N : 12 Nm - 3,200 Nm
- Ratios
1-stage : 1/1.5/2/3/4/5
2-stage : 7/10/15/20/25/35/50
3-stage : 75/100/125/150/200/250/350/500
- Low backlash
1-stage : ≤6arcmin
2-stage : ≤8arcmin
3-stage : ≤10arcmin
- high efficiency
1-stage : ≧ 98%
2-stage : ≧ 94%
3-stage : ≧ 94%
- Easy mount
- Low Noise
- Compact structure
|
|
All sizes available:
AT065FL / AT075FL / AT090FL / AT110FL / AT140FL / AT170FL / AT210FL / AT240FL / AT280FL |
| |
|
|
