  PN Series

PN-Series

Special design for continuous(S1) or cyclic(S5) duty operation

Overview

  • Output torque
    T2N : 9 Nm - 423 Nm
  • Ratios
    1-stage :  3/4/5/7/10
    2-stage :  15/16/20/25/30/35/40/50/70/100
  • Low backlash
    1-stage : 8 arcmin
    2-stage : 10 arcmin
  • high efficiency
    1-stage : ≧ 97%
    2-stage : ≧ 94%
  • Easy mount
  • Low Noise
  • Compact structure

Size

All sizes available:
 PN023 / PN034 / PN042 / PN056 / PN075

@

@

@

@

PN Type

  PN Series



Standard Download



Motor Mounting Instructions



Download Catalogue

@
@ @
