AB-Series

Special design for continuous(S1) or cyclic(S5) duty operation

Overview

• Output torque
  T_2N : 14 Nm - 2000 Nm

• Ratios
  1-stage : 3 / 4 / 5 / 6 / 7 / 8 / 9 / 10
  2-stage : 15 / 20 / 25 / 30 / 35 / 40 / 45 / 50 /
                60 / 70 / 80 / 90 / 100

• Low backlash
  1-stage : ≤1arcmin / ≤3arcmin / ≤5arcmin
  2-stage : ≤3arcmin / ≤5arcmin / ≤7arcmin

• high efficiency
  1-stage : ≧ 97%
  2-stage : ≧ 94%

• Easy mount

• Low Noise

• Compact structure

Size
